Sugatsune HG-VH8-T35/WT: Free Stop Combination Hinge - White
Sugatsune HG-VH8-T35/WT: Free Stop Combination Hinge - White

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

Sugatsune HG-VH8-T35/WT: Free Stop Combination Hinge - White

Sugatsune
|
SKU: suga-HG-VH8-T35/WT
In stock
(0)
$15.90
-15% $18.70 $15.90
Usually Ships In 1 to 3 Business Days

Have Questions? Ask an Expert!

888-566-2748 Email Us
Sugatsune HG-VH8-T35/WT: Free Stop Combination Hinge in White finish.
  • Free stop movement, holds where set
  • Lightweight hinge for lids and doors
  • 270 degrees opening angle
  • Torque rating: 3.10 lbs./inch per hinge
  • Torque calculation: Toque = Door height x .5 x door weight
  • Maximum weight for lateral opening door: 1.78 lbs.
  • Sold individually
  • Mounting hardware not included

Specifications

Height: 0.49″
Width: 1.42″
Depth: 1.97″
