Sugatsune LIN-X1000/BL-S: MonoFlat 19mm Overlay Lateral Opening Door System - Black
Regular price
$2,917.20
Regular price
-15%
$3,432.00
Sale price
$2,917.20
IMPORTANT!
This item has specific information available that should be reviewed before purchasing. Please click the button below to see more.
View Sugatsune CatalogProduct requires special shipping, please contact us at 888-566-2748 in order to get an estimate.
Couldn't load pickup availability
Have Questions? Ask an Expert!
Sugatsune LIN-X1000/BL-S: MonoFlat 19mm Overlay Lateral Opening Door System in Black finish.
- Lateral opening mechanism that allows door to swing out laterally in a small radius, ideal for tight space applications
- Designed for overlay installations, but can be installed flush with the surrounding wall or cabinets.
- Can be used in double door and blind corner applications
- Four-way adjustable: vertical, horizontal, depth and parallel
- Built-in dampers provide smooth soft-close movement
- Non-handed
Door Dimensions:
- Door width: 29-1/2" to 43-5/16"
- Maximum height: 117-5/16"
- Thickness: 15/16" to 1-9/16"
- Maximum weight: 198 lbs./door
Kit includes:
- 1 x upper arm
- 1 x lower arm
- 1 x 2000mm (78-3/4") connecting rod
- 4 x Hinge side mounting plates
- 4 x Door side mounting plates
- 1 x Damper
