Sugatsune LIN-X1000/WT-S: MonoFLat 19mm Overlay Lateral Opening Door System - White
Sugatsune LIN-X1000/WT-S: MonoFLat 19mm Overlay Lateral Opening Door System - White

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

Sugatsune LIN-X1000/WT-S: MonoFLat 19mm Overlay Lateral Opening Door System - White

Sugatsune
|
SKU: suga-LIN-X1000/WT-S
In stock
(0)
$2,431.00
-15% $2,860.00 $2,431.00
Usually Ships In 1 to 3 Business Days

Product requires special shipping, please contact us at 888-566-2748 in order to get an estimate.

Have Questions? Ask an Expert!

888-566-2748 Email Us

Sugatsune LIN-X1000/WT-S: MonoFLat 19mm Overlay Lateral Opening Door System in White finish.

  • Lateral opening mechanism that allows door to swing out laterally in a small radius, ideal for tight space applications
  • Designed for overlay installations, but can be installed flush with the surrounding wall or cabinets.
  • Can be used in double door and blind corner applications
  • Four-way adjustable: vertical, horizontal, depth and parallel
  • Built-in dampers provide smooth soft-close movement
  • Non-handed

Door Dimensions:

  • Door width: 29-1/2" to 43-5/16"
  • Maximum height: 117-5/16"
  • Thickness: 15/16" to 1-9/16"
  • Maximum weight: 198 lbs./door

Kit includes:

  • 1 x upper arm
  • 1 x lower arm
  • 1 x 2000mm (78-3/4") connecting rod
  • 4 x Hinge side mounting plates
  • 4 x Door side mounting plates
  • 1 x Damper
