Sugatsune LIN-X600: MonoFlat Lateral Opening System for Medium Cabinet Doors
- Innovative laterally opening hinge system allows door to swing open in a small radius
- Can be installed flush with the surrounding cabinetry or wall
- Hinge allows door to freely stop in any opened position
- Damper function produces soft, self-closing movement
- Hardware does not require tracks/rails on floor or ceiling of cabinetry
- Designed for standard 32mm system mounting with snap-on hinge for easy installation
- Use LIN-X on new or existing cabinets
- Available as a standard kit or components for custom installations
- Designed for use in single or double door configurations in a variety of settings
- 19mm overlay
- 4-way adjustability
- Optional face frame bracket available (suga-FFCB-HG-1), sold separately
- Width: 21-5/8" to 25-9/16"
- Height: 23-5/8" to 35-7/16"
- Thickness: 5/8" to 15/16"
- Maximum Weight: 19.8 lbs.
- Two hinge arms with dampers
- Two mounting plates
- One 540mm long connecting bar
- Two connecting bar end caps
- Mounting screws
