Sugatsune SDR-A84D-4D-4HDC: Folding Door Hardware Kit

Sugatsune
|
SKU: suga-SDR-A84D-4D-4HDC
Out of stock
(0)
$813.45
-15% $957.00 $813.45

Pricing starts at $813.45 and may vary based on selected options, finishes, and mounting styles. For a personalized quote, please contact customer service at 888-566-2748.

Have Questions? Ask an Expert!

888-566-2748 Email Us

Sugatsune SDR-A84D-4D-4HDC: Folding Door Hardware Kit

Features

  • Four door assembly
  • Quiet, precision movement
  • Low profile gap of 3/16"
  • Top recessed mounting for four doors
  • Double rollers with ball bearings
  • Includes 6 concealed hinges
  • Optional bottom track available, sold separately (not required)

Door Dimensions

  • Maximum weight: 66 lbs. per panel
  • Thickness: 1-3/8" to 2"
  • Minimum door panel width: 21-1/32"
  • Maximum door panel width; 29-1/2"

Track Options (all items sold separately). A top track is required, bottom guide channel is optional

  • Standard Top Track, 78-3/4" (2000mm): suga-SDR-A84D-2000
  • Standard top Track, 118-1/8" (3000mm): suga-SDR-A84D-3000
  • False Ceiling Top Track, 118-1/8" (3000mm): suga-SDR-A84D-TC-3000
  • Bottom Guide Channel (optional): suga-SDR-A-4131
  • Bottom Guide Roller (optional): suga-SDR-A-4110
